Electric Radiant Floor Heating Systems & Parts Thermostats

Electric Radiant Floor Heating Systems & Parts Thermostats

Radiation heating is possible to implement a more economic and pleasant heating environment without smell or smoke.

Cost efficiency compared to other existing heating systems which are powered by oil or gas, etc.

Flame retardant and water-proof outer jacket emits zero electromagnetic fields and is well protected from electricity leakage.

Safety and uniform temperature distribution are guaranteed due to double&nbsp shielded with ground for easy installation and programmed thermostats to conveniently and fast control the temperature and avoid malfunctions.

High Durability and No Maintenance. Thanks to the double layer structure, it has high durability and it is not necessary to manage and maintain the system separately.

Environmental friendly product approved by CE, RoHS and PCT certificate.

Applied for dry and wet locations.

Helpful to human& health as it raises the heat from floor and keeps the lower part (legs) warm while the upper part (head) cool.

 Programmable Room Thermostat

ANLT07H - Programmable Touch Screen Thermostat

Power Supply: 85-250VAC

Display resolution: 0.1℃

Setting Unit: 0.5℃/step

Internal sensor measurement range: 0 - 40℃.

Setting range: 5 - 35℃ (default: 25℃)

Inside sensor: NTC B=3380 10k

@25degrees Celsius

Max. switch power: 3A/16A/30A

External sensor measurement range: 0 - 99℃.

Setting range: 5 - 95℃ (default: 50℃)

Extra sensor: NTC B=3380 10k @25 degrees Celsius, length=3 meters

Display type: LCD

Display area: 60 x 45 mm

ANLTE52 - Programmable Digital LCD Display Thermostat

Applicable for hot water radiant and electric heating system.

Voltage: 220±10%VAC, 50/60Hz
Room setting Range: 1℃~50℃ (can adjust to 15℃~90℃)

External limitation: 20℃~90℃ (factory setting 65℃)

Sensor type: NTC

Color: white ivory

Mounting: mounts directly onto wall or wall-box

Relative humidity: <85% (23℃)

Size of display: 58 mm X 35mm (H/W)

ANLT8600 - Programmable Floor Heating Room Thermostat

Power Supply: 100-240VAC 50/60Hz
Power consumption: <1.5w
Setting Time + Black light + Large LCD screen Accuracy: ±1℃
Timing error: <1%
Temperature re-range: 5 - 35℃
Rubber-thermoplastic NTC Sensor Housing material:self-extinguishing PC

ANLT71.36 - Knob / Manual Thermostat

Voltage: 220AVC+/-15% 50/60Hz
Power consumption: 3.5A
Re-range:5-30 Celsius
Maximum load:16A 3000W
Double control, LED indication working
Setting range: 10 ~55℃
Ambient temperature: -5~55℃
Protective housing: IP20

ANLTC70 - Temperature Controller

Power supply: 230 V 50 Hz
Power consumption: 5 W
Adjusting range: 5°C ~ 40°C

Differential per. temp. : 0.5°C
Operating temp.: - 5°C ~ 50°C

Degree of protection: IP20
Material: self-extinguishing PC Floor sensor: NTC sensor 3 m

Q: Is electric heating system a big consumer of electricity?

A: The running cost of a heating mat will depend on the following conditions.
1.How well insulated the room is;
2.The output and type of system;
3.The energy tariff in your country;
4.The thermostat settings of your choice.

Below is the examples of monthly running electricity consumption for ANLT standard 12w/m 150w/m2 electric heating mat.

Q: What are the floor material requirements for installing the ANLT Heating Cable Floor Radiant Heating System ?

A:Tile: Ceramic, Porcelain, Natural Stone (Marble, Granite, Slate, Travertine, Limestone and others) Engineered Wood, Laminate, Vynil

Q: Do I need an electrician to install ANLT Floor Heating Systems ?

A: ANLT Floor Radiant Heating Systems are easy and quick to install. But you need a certified and qualified electrician to connect your thermostat to the house.

Q: Can the cold leads be extended?

A: Yes. The cold lead wires can be trimmed or lengthened with additional lead wire. However, please keep in mind that the heating able mustn′t be cut at any time.
