Brand Name: ICEUPS
Model Number: KMB-5T
Place of Origin: Guangdong, China (Mainland)
Condition: New
Capacity: 5000kg/24h
Ice Shape: Ice Block
Voltage: 380v/50hz/3p
Power(W): 23.85kw
Dimension(L*W*H): 4400x1700x1200mm
Weight: 1500kg
Certification: CE
Warranty: 12months
After-sales Service Provided: Engineers available to service machinery overseas
Ice Machine Type: Automatic block ice maker 1ton per day
Ice mold: Stainless Steel 304
Ice Block size: 280x260x750mm
Refrigerant: R404a
Cooling way: water cooling
water supply: freshwater
standard Power supply: 380V 50Hz 3Ph
Output Ice time: 2 hours/42pcs
Compressor Brand: Danfoss
evaporating temp.: -18℃
ICEUPS Brine system industrial ice block making
According to your requirements to set ice making machine,it is automatic cleaning,automatic disinfection time and cycle tips, safe and secure.
Model: KMS-5T
Standard Working Condition:Ambient Temp: 25℃, Water Inlet Temp: 18℃
Applicable Condition: Ambient Temp: 5℃-40℃, Water Inlet Temp: 0.5℃-25℃
Ice Block weight: 2kg,5kg,10kg,15kg,20kg,25kg,50kg,100kg
Refrigerant: R22/R404A
Block Ice Machine 1Ton
Daily capacity | 5000kg/24h |
Refrigeration capacity | 41/h |
Power Consumption | 23.85kw |
Machine Dimension | 4400x1700x1200mm |
Ice Block size | 120x90x600mm(2kg/pcs) |
Ice output time | 2hrs/time |
Cooling way | air cooling |
Refrigerant | R404a |
Power Supply | 380v/3p/50hz |
Water Pressure | 0.1mp~0.5mp |
Evaporating Temp. | -19 ℃ |
Condensing temp. | 40 ℃ |
Weight | 1500kg |
Ice mold quantity | 42 pcs |
1. packed by standard export wooden box
2. shipping terms: FOB Shenzhen,China or CIF your Port
We provide 12months warranty and free parts within warranty period
After shipment, we will send you the user manual of ice machine
