Brand Name: ICEUPS
Model Number: KMS-8T
Place of Origin: Guangdong, China (Mainland)
Condition: New
Capacity: 8T/day
Ice Shape: Flake Ice
Voltage: 380V/3 P/50hz/
Power(W): 31.5kw
Dimension(L*W*H): 2530*1830*1680
Weight: 978kg
Certification: CE
Warranty: 12months
After-sales Service Provided: Engineers available to service machinery overseas
product name: new condition and CE certification flake ice maker
Compressor: Copeland/Bitzer/Hanbell
Ambient temp: 5~45°C
Control system: PLC + touch screen
Water supply: Fresh water
Expansion valve: DANFOSS
Cooling Model: Air cooling or water cooling
Installation Model: Spit install or all-in-one
Ice bin: Customized
Refrigerant: R404A/R22/R717/R507
new condition and CE certification flake ice maker
Structural Drawing
Specification
Model | KSM-8T | Brand | ICEUPS |
Daily Capacity(kg) | 8000 | Cooling Model | Water cooling |
Ref. refrigerating capacity(kw) | 18 | Installation power(kw) | 31.5 |
Standard ambient temp(°c) | 28 | Reducer power(kw) | 0.75 |
Standard Water inlet temp(°c) | 18 | Water pump power(kw) | 0.18 |
Evaporating temp(°c) | -20 | Power supply | 3P/380V/50ZH |
Condensing temp(°c) | 40 | Refrigerant | R404A |
Compressor brand | Copland | Unit dimension(mm) | 2530*1830*1680 |
Compressor structure | Hermetic vortex | Ice bin type | 2600*2000*2000 |
Compressor power(hp) | 40 | Ice bin dimension(mm) | Integral type |
Control model | PLC+Touch screen | Net weight (kg) | 978kg |
Sorry for no further notice if any technical innovation
Machining process
Foreign customers visiting
Project cases
1. Standard wooden case.
2. Complete ice machine contains: ice machine, cooling tower, water pump, water pipes and water pipe fittings in container.
3. For small machine, users only need to connect power supply and water supply to make machine working; for big machine, we will send engineer to guide installation.
4. All required components for installation will be provided
Domestic shipping International shipping
1. Standard voltage (0.2T-0.5T) 220V / Singel Phase/ 50hz , (1T-30T) 380V/3 phase/50hz ,
Customize Non-standard voltage is available
2. Integral type installation ( Refrigerating unit + evaporator ).
Split installation is available
3. FOB price is default price.
EXW,C&F,CIF are available
