Electric underfloor heating loose wire

FOB Price:

US 12-100 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

1500 Piece/Pieces per Week

Port:

shanghai

Place of Origin:

Jiangsu, China (Mainland)

Payment Terms:

L/C,T/T,Western Union,paypal

Brand:

senphus

Products Model:

SHHM150

Products Details
Company Profile

Quick Details

Brand Name: senphus

Model Number: SHHM150

Place of Origin: Jiangsu, China (Mainland)

Packaging & Delivery

Packaging Details: carton, color box
Delivery Detail: 10 days

Specifications

Electric underfloor heating loose wire

Senphus electric underfloor heating loose wire can be controlled by a single underfloor heating thermostat.

Senphus Loose Wire comes with :

Loose Wire Underfloor Heating System.
Digital Programmable air and floor thermostat.
Floor Probe. included with Thermostat
High adhesion fixing tape.
Lifetime warranty on heating system.
Full fitting instructions and Technical Free Phone Help Line.

Senphus underfloor heating loose wire technique data:

Voltage	Size	Power/W	Ohm	Length(m)	The power line length	Out Diameter
230	SHDN-20-10M(A)	200	264.50	10	3C 0.5mm2 L=2M black	5.0±0.1mm
230	SHDN-20-15M(A)	300	176.33	15	3C 0.5mm2 L=2M black	5.0±0.1mm
230	SHDN-20-25M(A)	500	105.80	25	3C 0.5mm2 L=2M black	5.0±0.1mm
230	SHDN-20-30M(A)	600	88.17	30	3C 0.5mm2 L=2M black	5.0±0.1mm
230	SHDN-20-35M(A)	700	75.57	35	3C 0.75mm2 L=2M black	5.0±0.1mm
230	SHDN-20-42.5M(A)	850	62.24	42.5	3C 0.75mm2 L=2M black	5.0±0.1mm
230	SHDN-20-60M(A)	1200	44.08	60	3C 0.75mm2 L=2M black	5.0±0.1mm
230	SHDN-20-80M(A)	1600	33.06	80	3C 1.0mm2 L=2M black	5.0±0.1mm
230	SHDN-20-90M(A)	1800	29.39	90	3C 1.0mm2 L=2M black	5.0±0.1mm
230	SHDN-20-100M(A)	2000	26.45	100	3C 1.0mm2 L=2M black	5.0±0.1mm
230	SHDN-20-120M(A)	2400	22.04	120	3C 1.5mm2 L=2M black	5.0±0.1mm
230	SHDN-20-140M(A)	2800	18.89	140	3C 1.5mm2 L=2M black	5.0±0.1mm
230	SHDN-20-160M(A)	3200	16.53	160	3C 1.5mm2 L=2M black	5.0±0.1mm
