Brand Name: Mgreenbelt
Model Number: MG-140WS
Place of Origin: Shandong, China (Mainland)
Condition: New
Type: Water-Cooled
Cooling Capability(kw): 444.4KW
Voltage: 380v,415v,440v,460v,480v
Dimension(L*W*H): 3800x900x1800mm
Weight: 1850KGS
Certification: CE
Warranty: 12-month
After-sales Service Provided: Engineers available to service machinery overseas
Water cooled chiller condenser: Shell and tube
Cooling tower water: 101.6m3/h
Evaporator: Shell and tube
Chilled water: 76.2m3/h
Screw compressor power: 94.4kw
Start method: Y-delta
Chiller capacity control: 25%,50%,75%,100%
Keywords: energy efficient chiller, chiller cooling tower system
120TR Screw Water Cooled Chiller Cooling Tower System Energy Efficient Chiller
Description of Industrial Water Cooled Chiller | |
Water Cooled Screw Chillers are widely used in phamaceutical, chemical, plastic injection, extrusion, plating, mold, hydraulic, chemical, leather, printing, profiles of oxidation, reaction kettle, chemical fiber, vacuum coating, paper making, textile, central air conditioning and other industries. | |
Specification of 120TR Screw Water Cooled Chiller Cooling Tower System | |
Model | MG-140WS |
Chiller plant working cycle voltage | 380v,415v,440v,460v,480v |
Refrigerant gas | R407c,R22,R134a |
Outlet water temperature | 5-30°C |
Cooling capacity | 444.4kw |
Screw compressor power | 94.4kw |
Start method | Y-delta |
Capacity control | 25%,50%,75%,100% |
Chiller evaporator | Shell and tube |
Chilled water | 76.2m3/h |
Water cooled condenser | Shell and tube |
Cooling tower water | 101.6m3/h |
Water screw chiller sizing | 3800x900x1800mm |
![]() |
![]() |
![]() |
Chiller Circulating Water System Cycle
Industrial Water Cool Condenser Chiller with Cooling Tower Parts
Package and Delivery
Water Cooled Industrial Chillers For Sale
Water Cooled Refrigeration Cycle Chiller Plant
Services:
1. Warranty: 12 Months.
2. Customerized accept.
3. All extral parts for the machine can be purchased by agent price from Mgreenbelt.
4. Technical support and after-sales service free of charge.
5. Professional technical team and Sales give troubleshooting procedures.
6. Door-to-door service if necessary.
Mgreenbelt industrial water chiller manufactures air cooled water chiller, water cooled water chiller, stainless steel chiller, screw chiller from 3.5KW(1Ton)to 1500KW(500Ton), oil chiller, mold temperature controller units, cooling tower, shell and tube heat exchanger and all refrigeration spare parts.
