IQF Flow Freezer/IQF Bed Freezer/IQF Fluidized Quick Freezer Machine

FOB Price:

US 40,000-999,999 / Set

Min.Order Quantity:

1 Set/Sets

Supply Ability:

1 Set/Sets per Month

Port:

Ningbo,China

Place of Origin:

Zhejiang, China (Mainland)

Payment Terms:

L/C,T/T

Brand:

WUYE

Products Model:

SLD

Products Details
Company Profile

Quick Details

Brand Name: WUYE

Model Number: SLD

Place of Origin: Zhejiang, China (Mainland)
Condition: New
Type: IQF Freezer
Voltage: Local
Power(W): Machine Model
Dimension(L*W*H): Machine Model
Weight: Machine Model
Certification: ISO9001
Warranty: 1 Year
After-sales Service Provided: Engineers available to service machinery overseas
Material: Food Grade Stainless Steel
Application: freezing food
Freezer Type: Iqf freezing tunnels
Product name: IQF Flow Freezer

Packaging & Delivery

Packaging Details: IQF Flow Freezer is naked and packed by wooden
Delivery Detail: Shipped in 65 days after payment

Specifications

Product Description

IQF Flow Freezer/IQF Bed Freezer/IQF Fluidized Quick Freezer

Machine

Fluidized IQF Freezer is Fluidized freezers are mostly used for flour food freezing, fruits & vegetables freezing, and prepared food freezing .in quick-freezing strip, cubic or grain food, such as shrimp meat, shrimp, sliced fish, meat dumpling, divided meat, pig tongue, chicken, asparagus and yam. It saves energy and is convenient in cleaning and maintenance.

Fludizied IQF Freezer
Molde	SLD-500	SLD-1000	SLD-2000	SLD-3000	SLD-4000	SLD-5000
Capacity	500kg/h	1000kg/h	2000kg/h	3000kg/h	4000kg/h	5000kg/h
Machine size(meter)	7.1×4.4×3.2	9.6×4.4×3.8	10.8×4.4×3.8	13.1×4.7×4.4	16.1×4.7×4.4	19.6×4.7×4.4
Infeed Tem.	15℃
Outfeed Tem	-18℃
Inner circulation temperature	-35±2℃
Frozen Time	3-60min
Refrigerant	R22 or R717 or R404a

Traits
1	High freezing rate, frozen product category multi.
2	To actualoze mono,er freezing continunous.
3	Low energy consumption
4	Fast freezing under -32℃
5	The freezer can deal with various product, it is even apply to sea food, such as scallp, shelled fresh shrimp, fillets et.
6	Defrosting long intreval of time

Advantages

1.Evaporator

Adopt aluminum duct and aluminum sheath, particular design of different fin pitches, prolong the defrosting intreval of time.

2.High press air cooler

Pledge the freezing product gets along with suspend athletics estate, prevente from bonded together.

3.Evaporation temperature

Freezing temperature is -32 ℃

Mesh Belt

Internal Structure

Inlet

Feeding

Outting

Certifications

Our service

1. Free training for your needed , and the list of related equipment, operating procedures for your company's technical

staff in the future production process equipment repair and maintenance of strong backing.

2. After sale: we'll help install and testing the machines,then we'll teach customer to operate the machines and repair
them. if have big problem ,we'll send engineer to customer side.
3. Implementation quality one year warranty and lifetime service.
4. My company will be ISO 9001: 2008 quality system as a platform seriously good quality, the most reasonable price,

best quality , the most innovative and the best service to provide your company with first-class equipment, and

sincerely cooperate with you
