Brand Name: GALA
Model Number: 3226
Place of Origin: Tianjin, China (Mainland)
Standard or Nonstandard: Standard
Structure: Gate
Pressure: High Pressure
Power: Manual
Material: Casting
Temperature of Media: Normal Temperature
Media: water,oil,gas
Port Size: DN50-DN300
Application: General
Certificate: ISO9001,CE
Honor: Name-Brand
Company Type: Manufacturer and trading company
Working pressure: 16 bar
Color: blue
Working Pressure: 16bar stem gate valve
Construction: NRS type gate valve
Operator: Hand wheel stem gate valve
OEM: available
Time warrantee: 2 year
Standard and Price | |
FIG NO. | 3226 |
Price Range | $20-$424 |
Valve Standard | Comply with AWWA C509 |
Pressure Temprature and Rating | |
Working Pressure | 200psi |
Testing Pressure | Shell: 300psi |
Seal: 220psi | |
Working Temperature | -4°C to 230°C EPDM |
14°C to 176°C NBR |
Material Specification | ||
Part | Material | ASTM |
Body | Ductile Iron | A536 Gr. 65-45-12 |
Bonnet | Ductile Iron | A536 Gr. 65-45-12 |
Disc | EPDM Coated DI | A536 Gr. 65-45-12 |
Stem | Stainless Steel | AISI 420 |
O-Ring | EPDM/NBR | Commercial |
Hand Wheel | Ductile Iron | A536 Gr. 65-45-12 |
Company Information:
COMPANY INFORMATION
TIANJIN GALAXY VALVE CO.,LTD is an export-oriented Sino-US joint valve manufacturer established in 2004, which has strong capability of R&D, manufacturing, trading and service. It owned registered assets of 50 million RMB, and total assets of more than 100 million RMB. Tianjin Galaxy Valve has been certificated by ISO9001 QMS, European EC, and entitled to engage in import and export business, and has obtained the Type Approval certificates of DNV/ABS/CCS. It is also a member of China Valve Industrial Association, one of approved vendors of China Petrochemical market, and has obtained National Manufacture License of Special Equipment.
Tianjin Galaxy Valves’ products covered kinds of butterfly valves, check valves, strainers, gate valves, ball valves, globe valves, balancing valves, with pressure range from 0.5–6.4Mpa, size from DN15-DN3000. The products have been widely used to national key projects, for example, Three Gorges Project, Jiuquan Satellite Launch Base, 2010 Shanghai World Expo water supply and drainage project, Tianjin Dagang Power Plant seawater cooling and desalination project, Guangxi Sino-French joint venture Laibin Power Plant, CNOOC Shanghai petrochemical project, Tianjin Zhonggang shipping projects. The products also have been widely exported to more than 30 countries and regions, such as USA, Canada, UK, France, the Netherlands, Italy, Australia, Souch Africa, Malaysia, Singapore, Hong Kong and so on.
Tianjin Galaxy Valve treats quality as lifeblood of the company, and total quality management has been carried out. Quality is the key to make company stronger. Tianjin Galaxy Valve is always persevering in supplying perfect and satisfying valves by strict total quality. Tianjin Galaxy Valve sincerely wishes to establish good cooperation with world friends.
Services:
1.Newly developed facilities ensure high and stable quality.
2.Experienced technology.
3.Excellent after-sale service to satisfy customers.
4.Sufficient capacity ensures prompt delivery.
5.Continuous quality improvement and new designs development.
6.Reasonable and stable price.
7.Meets different countries standards, such as ANSI,DIN,BS etc.
8.We are applying for LR,DNV, Foundry Works Approval.
9.OEM is available.
